04 — STATIONS
Two terminals, built for the crossing
Singapore's Woodlands North is underground and woven into the TEL; Johor's Bukit Chagar rises beside JB Sentral. Both stack immigration, concourse and platforms so you clear out before you board. Explore each, level by level.
Woodlands North — sectional layout
Underground terminus · co-located with Thomson–East Coast Line (TE1) · ~10× a typical MRT station
GSTREET
Entrances & drop-off
TEL link, bus stops, taxi/private-hire bays, bicycle racks.
TEL transferBusTaxi/PHC
B1CONCOURSE
Ticketing & retail concourse
Ticket machines, Passenger Service Centre, F&B and shops, toilets, prayer room.
TicketsPSCF&BSurauToilets
B2CIQ
Immigration & Customs (CIQ)
Singapore + Malaysia clearance side by side — auto e-gates, family/assisted lanes.
SG immigrationMY immigratione-GatesCustoms
B3PLATFORMS
RTS Link platforms 1–4
Spanish solution: board on island platforms 2 & 3, arrivals exit via side platforms 1 & 4. Full platform screen doors.
P1 · arrP2 · depP3 · depP4 · arr
Bukit Chagar — sectional layout
Elevated terminus · beside JB Sentral, Johor Bahru city centre
L4PLATFORMS
RTS Link platforms
Elevated boarding platforms with full platform screen doors, feeding directly onto the marine viaduct.
DeparturesArrivalsPSDs
L3CIQ
Immigration & Customs (CIQ)
Malaysia + Singapore clearance co-located, with assisted lanes for families and the elderly.
MY immigrationSG immigrationCustoms
L2CONCOURSE
Concourse & retail
Ticketing, Passenger Service Centre, retail and F&B, toilets, prayer rooms.
TicketsPSCRetailSurau
GARRIVAL
Ground arrival hall
Direct link to JB Sentral, buses, taxis and KTM intercity services.
JB SentralBusTaxiKTM
What's inside
Accessible
Prayer rooms
Family rooms
Toilets
F&B & retail
Service centre
